KR Series Professional Industrial Ultrasonic Cleaner

PRODUCTS RECOMMENDED

KR series ultrasonic cleaner is professional industrial ultrasonic cleaner to wash different industrial components quickly. Its transducers arrangement is multi-direction and different from most ultrasonic cleaners in the market, which can achieve more efficient and better cleaning result.

    • Ultrasonic transducers are uniformly mounted in multi directions of cleaning tank for more homogenous, thoroughly and better cleaning efficiency.

    • KEER new generation circuit board has stronger power and more stable.

    • Fast degassing function at the start of the ultrasonic cycle to remove gases from the solution for maximum ultrasonic cleaning performance.

    • Auto-tune technology with Sweep and power adjustment for more stable and better effect.

    • Original Germany CeramTec piezoelectric ceramic chip, good quality assurance.

    • Full-bridge IGBT module, high pressure resistant & high temperate resistance.

    • Transducers are fixed by stud welding and Switzerland glue to avoid shedding.

    • Ultrasonic power adjustable linearly.

    • SUS304/SUS316 thickening stainless steel, acid-proof and alkali-resisting with long work life.

    • Bigger cleaning tank size for choosing is suitable for different industrial cleaning requirements.

    • Cleaning objects are easily taken out by stainless steel cleaning basket.

    • Cleaning liquid heating function for better cleaning effect.

    • Double-layer & heat-retaining lid to prevent heat loss and save energy.

    • Machine lid with gas struts.

    • Fixed foot and casters with brake, easy to fixation and move.

    • Equipped with dregs groove to drain dregs easily.

    • Overflow device.

    • Components and parts come from world-famous brands.

    • Special tank size and requirement can be customized.


  • ModelTank Inner SizeTank Outside SizeEffective Liquid LevelMax. Tank CapacityEffective Tank CapacityUltrasonic PowerTransducerHeating Power
    KR-2400600x480x450mm760x770x680mm390mm130L112L2.4 KW100W, 24pcs4 KW
    KR-3000750x550x480mm910x850x770mm390mm198L160L3.0 KW100W, 30pcs8 KW
    KR-40001000x550x560mm1160x850x870mm420mm308L231L4.0 KW100W, 40pcs12 KW
    KR-60001200x650x650mm1400x1030x980mm490mm507L382L6.0 KW100W, 60pcs15 KW
    KR-80001450x720x730mm1650x1190x1100mm570mm762L595L8.0 KW100W, 80pcs18 KW
    KR-108001500x800x800mm1700x1280x1150mm640mm960L768L10.8 KW100W, 108pcs30 KW
    KR-120001700x900x800mm1960x1450x1150mm640mm1224L979L12.0 KW100W, 120pcs45 KW or Steam
    KR-240002500x1200x1000mm2800x1800x1350mm840mm3000L2520L24.0 KW100W, 240pcs90 KW or Steam
    • Ultrasonic Wave Direction: All the transducers are regularly fixed in three sides of cleaning tank.

    • Ultrasonic Frequency: 20 / 28 / 40 KHZ, Single

    • Ultrasonic Power Adjustable Range: 20% ~ 100%

    • Tank Material: SUS304, thickness 2mm

    • Supply Voltage: Ultrasonic generator 220V, 50Hz, 1Ph or 380V, 50Hz, 3Ph+N+PE; Cleaning tank 380V, 50Hz, 3Ph+N+PE.

    • Standard Configuration: Stainless steel cleaning tank, stainless steel cleaning basket, ultrasonic generator.

    • Optional Configuration: Circulating & filtration system, cleaning detergent, customized power supply.

  • 20200518133054799.jpg





  • cleaning effect
